Description
Introducing the Lumag RP-i38DE Diesel Compactor Plate, the pinnacle of power and efficiency for professional-grade compaction on construction sites, gardening, landscaping, foundation, and sewer construction. With its robust construction and powerful diesel engine featuring EURO V emissions standards, this vibratory plate is engineered to deliver reliable performance in even the most demanding environments.
Weighing 292 kg and boasting a slim design, the RP-i38DE is perfectly suited for efficiently and effectively working on larger areas. Its powerful diesel engine ensures dependable compaction performance, with a working width of up to 83 cm (with mounting plate) and a compaction depth of up to 90 cm.
Designed for ease of use and safety, the RP-i38DE features a sturdy steel housing and a folding handle for convenient transportation between job sites. Its hydraulic forward and reverse flow enable stepless speed control, providing precise maneuverability for optimal compaction results.
As the heavy model of reversible vibratory plates, the RP-i38DE excels at quickly and powerfully processing large areas in a small space. Its slim design allows for easy handling, even in tight spaces, ensuring maximum efficiency on every job.
Built to last, the RP-i38DE features a German-designed exciter with Japanese ball bearings, guaranteeing durability and reliability for commercial and residential use. The reinforced floor pulls not only make the work easier but also ensure a long service life, further enhancing its value as a dependable investment.
With its EURO V emissions standard, the RP-i38DE meets all requirements for environmental friendliness, making it a responsible choice for sustainable construction practices. Trust in the Lumag RP-i38DE Diesel Compactor Plate for unmatched performance, reliability, and environmental stewardship.
Specifications
Motor / drive | LC186FD diesel engine |
Engine power | 6.8 kW at 3,600 rpm |
displacement | 441 cm ³ |
Fuel tank | 4.5 l |
Board length | 830 mm |
Plate width | 480 mm |
mounting plate | 830 x 100 mm |
frequency | 63 Hz |
Centrifugal force | 38 kN |
Area performance | approx. 416 m ² / h. |
Max. Feed | 21 m / min. |
Vibration shocks | 3,750 vpm |
Compaction depth | 90 cm |
Max. Permissible inclined position of the engine | 20 ° |
Sound power level LWA | 108 dB ( A ) |
Operating weight | 292 kg |
Transport weight ( net / gross ) | 298/314 kg |
Packaging dimensions including pallet base ( LxWxH ) | 905 x 505 x 1130 mm |
Packaging dimensions cardboard box ( LxWxH ) | 905 x 505 x 1030 mm |
